Cámara cilíndrica AHD HD

ABS-F222-412
Las cámaras AHD se refieren a cámaras que utilizan tecnología analógica de alta definición (AHD), con resoluciones de alta definición de 720p o 1080p.

Características del producto

Parámetros de especificación

Características del producto
Cámara cilíndrica AHD HD

1/3’ CMOS image sensor, 1 million pixels, clear images

Low illumination 0.01Lux

Automatic exposure control ◎ Automatic white balance

Automatic black level correction

automatic gain control

940nm infrared lamp fills light, infrared is invisible to the naked eye

BMW head adapter, easy installation and wiring

Aviation connector, stable and reliable

Lens viewing angle direction can be adjusted up or down

High temperature resistant structure, suitable for installation and use in vehicle environment

Parámetros de especificación

Image Sensor

1/3 ' CMOS , 1 million   pixels

Effective Pixels

1280(H)×720(V)

video standards

AHD 1.0 , 720p

Video format

PAL

Frame rate

25fps , 1280×720

signal-to-noise ratio

≥45dB

Minimum illumination

0.01Lux

day and night mode

No IR-CUT   , night   vision automatically turns from color to black

infrared

IR LED   ( 940nm   )

electronic shutter

AUTO 1/50 ( 1/60 ) ~1/100,000sec

lens

2.2mm fixed focus HD lens

Horizontal viewing angle

130 °± 3 °

Audio

No pickup

power supply

50mA@DC12V   without   infrared, 110mA@DC12V with infrared

Line length

100cm ( BMW head extension cable 200cm )

shell

plastic,   black

weight

73g (excluding extension cord)

size

72.8mm×32.4mm

Operating temperature

-30 ℃~ 70   ℃

storage temperature

-40 ℃~ 85   ℃

Interface definition

aviation   connector
